Simple design, easy use;
High printing speed, 2.5-4 seconds per cassette;
Non contact UV laser technology;
Excellent ability to export characters, numbers, letters, 1D & 2D codes, graphics;
Fully compatible with LIS/HIS system;
Support color setting print;
10 inch LED touch screen via built-in software, also support to connect external PC;
Built in bar-code scanner, and support to connect external scanners;
Built in air purification system;
Compatible with various models of embedding cassettes on the markets
Technical Specification
Printing technology UV Laser Marking
Print speed 2.5-4 seconds/cassette
Print resolution 2500dpi
Cassette type Cassette with lid (one-piece)
Cassette with lid assembled (two-piece) or without lid
Loading hopper 4
Max Capacity Per Loading hopper 40 one-piece cassettes/100 two-piece cassettes or cassettes without lid
Compatible system Open to connect HIS/LIS systems
Dimension LxWxH 575mm x 228mm x 554mm
Weight 25kg
Power requirement 100-240 V AC 50/60Hz, 300VA
Other configuration 1. 10 inch touch screen;
2. Built-in bar-code scanner;
3. Bulit-in air purification system
Technical Specification
Printing technology UV Laser Marking
Print speed 2.5-4 seconds/cassette
Print resolution 2500dpi
Cassette type Cassette with lid assembled (two-piece)
Cassette without lid
Loading hopper 6
Max Capacity Per Loading hopper 100 cassettes with lid assembled or without lid
Compatible system open to connect HIS/LIS systems
Dimension LxWxH 486mm x 313mm x 497mm
Weight 37kg
Power requirement 100-240 V AC 50/60Hz, 300VA
Other configuration 1. 10 inch touch screen;
2. Built-in bar-code scanner;
3. Bulit-in air purification system
Simple design, easy use;
High printing speed, 2.5-4 seconds per cassette;
Non contact UV laser technology;
Excellent ability to export characters, numbers, letters, 1D & 2D codes, graphics;
Fully compatible with LIS/HIS system;
Support color setting print;
10 inch LED touch screen via built-in software, also support to connect external PC;
Built in bar-code scanner, and support to connect external scanners;
Built in air purification system;
Compatible with various models of embedding cassettes on the markets
Technical Specification
Printing technology UV Laser Marking
Print speed 2.5-4 seconds/cassette
Print resolution 2500dpi
Cassette type Cassette with lid (one-piece)
Cassette with lid assembled (two-piece) or without lid
Loading hopper 4
Max Capacity Per Loading hopper 40 one-piece cassettes/100 two-piece cassettes or cassettes without lid
Compatible system Open to connect HIS/LIS systems
Dimension LxWxH 575mm x 228mm x 554mm
Weight 25kg
Power requirement 100-240 V AC 50/60Hz, 300VA
Other configuration 1. 10 inch touch screen;
2. Built-in bar-code scanner;
3. Bulit-in air purification system
Technical Specification
Printing technology UV Laser Marking
Print speed 2.5-4 seconds/cassette
Print resolution 2500dpi
Cassette type Cassette with lid assembled (two-piece)
Cassette without lid
Loading hopper 6
Max Capacity Per Loading hopper 100 cassettes with lid assembled or without lid
Compatible system open to connect HIS/LIS systems
Dimension LxWxH 486mm x 313mm x 497mm
Weight 37kg
Power requirement 100-240 V AC 50/60Hz, 300VA
Other configuration 1. 10 inch touch screen;
2. Built-in bar-code scanner;
3. Bulit-in air purification system
