Large capacity with 360 slides at a time
Up to 15 programs, compatible with H&E, PAP and other staining
Simple and visualized touch screen operation frame to finish programing, operation and monitoring
High low step on tank to prevent lacking or reagent running out
activated carbon filtration to prevent pollution caused by volatilization of reagents
Round bottom structure cooperated with vibration to minimize residual access to next tank
Unique stir structure stirs all the hanging baskets simultaneously
Large capacity with 360 slides at a time
Up to 15 programs, compatible with H&E, PAP and other staining
Simple and visualized touch screen operation frame to finish programing, operation and monitoring
High low step on tank to prevent lacking or reagent running out
activated carbon filtration to prevent pollution caused by volatilization of reagents
Round bottom structure cooperated with vibration to minimize residual access to next tank
Unique stir structure stirs all the hanging baskets simultaneously
⊙ Surroundings requirements:
Working temperature：+10℃—35℃
Working humidity: <80%，defrosting
Working pressure:（86～106）KPa；
⊙ Power supply： 220 V AC/110VAC
⊙ Frequency： 50/60 Hz
⊙ Power： <350 VA
⊙ Fuse specification： 3A
⊙ Security classification：Class I- Type B
⊙ Sample slide quantity：300-600 slides per hour according to program
⊙ Load capacity： 12 baskets running maximum
⊙ Basket capacity： 30 sample sliders
⊙ Site quantity： 27
⊙ Reagent sites： 19 at least
⊙ Wash sites： 5
⊙ Dryer sites： none or 3 (optional)
⊙ upload/download sites： 6
⊙ reagent sites capacity： 450ML
⊙ Incubation time settings：0 second to 99 minutes 59 seconds
⊙ Program storage capacity：15，each program with 25 steps maximum
⊙ Colorful touch screen： 7 Inch
⊙ Outside dimension (LxWxH)：1050x680x600mm
⊙ Weight: about 116kg
⊙ Surroundings requirements:
Working temperature：+10℃—35℃
Working humidity: <80%，defrosting
Working pressure:（86～106）KPa；
⊙ Power supply： 220 V AC/110VAC
⊙ Frequency： 50/60 Hz
⊙ Power： <350 VA
⊙ Fuse specification： 3A
⊙ Security classification：Class I- Type B
⊙ Sample slide quantity：300-600 slides per hour according to program
⊙ Load capacity： 12 baskets running maximum
⊙ Basket capacity： 30 sample sliders
⊙ Site quantity： 27
⊙ Reagent sites： 19 at least
⊙ Wash sites： 5
⊙ Dryer sites： none or 3 (optional)
⊙ upload/download sites： 6
⊙ reagent sites capacity： 450ML
⊙ Incubation time settings：0 second to 99 minutes 59 seconds
⊙ Program storage capacity：15，each program with 25 steps maximum
⊙ Colorful touch screen： 7 Inch
⊙ Outside dimension (LxWxH)：1050x680x600mm
⊙ Weight: about 116kg
